1. Compact size for installation.
2. Easy operation.
3. Include check valves to prevent the reverse flow.
4. The system is recommended to applied to easier machinery system with the lubrication of lower requirement level.
5. Oil viscosity (40°C)： 20~150cSt.
| Model | YML-8 |
| Output Volume (cc/cy) | 8 |
| Max. output Pressure Mpa (kg/cm2) | 1.5 (15) |
| Tank Capacity (cc) | 600 |
| Effective Capacity (cc) | 450 |
| Output Bore | Ø4 or Ø6 |
| Direction of Bore | Left or Right |
| Weight (kg) | 1.4 |
Note： Because of continuous improvements, above specifications are subject to change without prior notice.
